SERIAL ........................ KM-7512
MODEL ......................... 9B
YEAR .......................... 1975
MAXIMUM LENGTH OF KEYWAY ...... 60"
MAXIMUM WIDTH OF KEYWAY ....... 5"
AREA OF TABLE ................. 48" X 48"
TABLE CAPACITY ................ 50,000 LBS
CUTTING SPEEDS ................ 4.0 TO 23 FPM
RETURN SPEED .................. 42 FPM
FEED RATE PER STROKE .......... .001 TO .009
LOW CUTTING FORCE CONTROL ..... UP TO 1"
MEDIUM CUTTING FORCE CONTROL .. MED 1-1/4"
HIGH CUTTING FORCE CONTROL .... OVER 3"
FLOOR TO TOP OF TABLE ......... 55"
PIT REQUIRED .................. YES
CONTROL PENDANT ............... YES
DEPTH CONTROL ................. YES
AUTOMATIC TOOL RELIEF ......... YES
*** TOOLING INCLUDED ***
Brand
MITTS & MERRILL
Type
Keyseaters
Stock No.
14144
