| X-Axis | 28.7" | 728.98 mm |
| Y-Axis | 20.1" | 510.54 mm |
| Z-Axis | 20.1" | 510.54 mm |
| Table Dia. | 19.7" | 500.38 mm |
| B-axis | +160° to −180° | +160° to −180° |
| C-axis | 360° | 360° |
| # Axis | 5 | 5 |
| Spindle Motor | 25 hp | 18.6 kW |
| Spindle Speed | 12,000 RPM | 12,000 RPM |
| ATC Capacity | 31 | 31 |
| Taper | HSK-A63 | HSK-A63 |
| Table Size | 19.7" x 19.7" | 19.7" x 19.7" |
| Table Load Capacity | 660 lb | |
| Dimensions | 109.1″ × 155.4″ x 128.5″ | 109.1″ × 155.4″ x 128.5″ |
| Weight | 27,280 Lbs | 27,280 Lbs |
Mori Seiki MSX-711 III MAPPS CNC Control
11,396 Hours Cutting Time
5-Axis Simultaneous Machining
Driven at the Center of Gravity (DCG) Structure
Renishaw Probing System (Probe Included)
Tool Presetter
Through-Spindle Coolant
MPG Handwheel Control
Spindle Chiller
