| X Axis Travel | 40.2" | 1,021.1 mm |
| Y Axis Travel | 21.3" | 541.02 mm |
| Z Axis Travel | 20.1" | 510.54 mm |
| Cutting Feed Rate | 590 IPM | 590 IPM |
| Rapid Traverse X | 1,417 in/min. | 3,599.2 cm/min. |
| Rapid Traverse Y | 1,417 in/sec. | 215,950.8 cm/min. |
| Rapid Traverse Z | 1,181 in/min. | 2,999.7 cm/min. |
| Distance From Spindle To Column | 5.9″ – 26" | 5.9″ – 26" |
| Spindle Motor | 12 hp | 8.9 kW |
| Spindle Speed | 8,000 RPM | 8,000 RPM |
| ATC Capacity | 30 | 30 |
| Spindle Taper | CAT40 | CAT40 |
| # Axis | 3 | 3 |
| Cut Hours | 4,127 hr. | 4,127 hr. |
| Table-W | 21.3" | 541.02 mm |
| Table-L | 47.2" | 1,198.9 mm |
| Max. Table Load | 1764 Lbs | 1764 Lbs |
| Dimensions | 116″ x 96″ x 107″ High | 116″ x 96″ x 107″ High |
| Weight | 14,330 Lbs | 14,330 Lbs |
FANUC i CNC Control
Thru Spindle Coolant
Renishaw Receiver Installed
USB Drive
PCMCIA Card Slot & RS-232 Port
MPG Hand Wheel Control
Automatic Lubrication System
Rigid Tapping
Coolant System
Spindle Chiller Unit
Levelling Pads
LNS Chip Conveyor
