| Swing | 31.5" | 800.1 mm |
| Machining Length | 68.89" | 1,749.8 mm |
| Chuck Size | 32" | 812.8 mm |
| Bar Capacity | 22.04" | 559.82 mm |
| Power | 50 hp | 37.3 kW |
| Max RPM | 500 RPM | 500 RPM |
| Turning Dia | 25.99" | 660.15 mm |
| Tailstock | Yes | Yes |
| Control | CNC | CNC |
Specifications (subject to buyer verification):
Swing Over Way Covers: 35.59"
Swing Over Saddle: 22.05"
Max Turning Diameter: XA - +25.99", XB - +19.68"
Swing Over Bed: 31"
X Axis Travel : XA - 12.99", XB - 10.41"
Z Axis Travel : ZA - 80.37", ZB - 39.9"
Work Range between centers (for tailstock machine): 68.89"
Spindle Nose: A2-20
Spindle Bore: 22.04"
Main Motor: 60 hp
Upper Turret: V 12
Lower Turret: V 8
Tailstock: MT No. 6
Equipped with (subject to buyer verification):
OKUMA OSP - P200L
Chip Conveyor
Variable Speed Threading
40" Schunk TB-100/560 LH Chucks
Tailstock
