Dayton 3N404 industrial motor. Pulled from a working environment but not tested by me. Heavy‑duty TEFC design, Class H insulation, and NEMA B performance. Ideal for compressors, pumps, conveyors, and general industrial applications.
Specifications
• Model: 3N404
• Horsepower: 5 HP
• RPM: 1745
• Voltage: 208 / 230 / 460 VAC
• Phase: 3
• Amps: 14.2 / 12.8 / 6.4
• Frame: 184T
• Enclosure: TEFC
• Service Factor: 1.15
• NEMA Design: B
• Insulation Class: H
• Duty: Continuous
• Max Ambient: 40°C
• Power Factor: 83.5
• Efficiency: 87.5%
• Max KVAR: 1.8
• Bearings: 6206 (shaft end), 6205 (opposite end)
• Motor Ref: W56‑T995A‑H
Wiring
• Low Voltage: 4‑5‑6 tied, 7‑8‑9 tied, L1‑1, L2‑2, L3‑3
• High Voltage: 4‑7, 5‑8, 6‑9, L1‑1, L2‑2, L3‑3
• Rotation reversible by swapping any two line leads.
