USED A -B 100-C30*00

The Allen-Bradley 100-C30*00 is a 30-amp, 3-pole IEC-rated contactor from the Rockwell Automation Bulletin 100-C series designed for motor control and load switching applications. This contactor features no built-in auxiliary contacts (indicated by the "-00" suffix), providing maximum configuration flexibility for custom applications. Built with industrial-grade plastics and metal contacts, it includes IP2X finger protection and built-in surge suppression.
Specification
Value
Brand
Allen-Bradley
Model/Part Number
100-C30*00
Product Type
IEC Contactor
Current Rating
30A
Poles
3
HP Rating 230V
10 HP
HP Rating 460V
20 HP
HP Rating 575V
20 HP
AC-3 Rating
30A
AC-1 Rating
65A at 690V
Maximum Voltage
690V
Enclosure Rating
55A Max at 600V AC
Short Circuit Rating
5kA at 600V
Impulse Withstand Voltage
8kV
Auxiliary Contacts Included
None (-00 suffix)
Maximum Auxiliary Contacts
6 total (4 front + 2 side mount)
Coil Voltage
See label (* indicates variable)
Terminal Type
Screw Terminals
Mounting Type
35mm DIN Rail or Panel Mount
IEC Standard
IEC/EN 60947-4-1
UL Rating
UL 508 Listed
CSA Certified
Yes
CE Marked
Yes
RoHS Compliant
Yes
Platform
Bulletin 100-C
Series
See label
We warranty all items for 30 days from date of purchase.

SKU: AI1115
UPC: 679523686161
Condition: Used
Availability: In Stock
Weight: 2.00 LBS
Width: 7.00
(in)
Height: 6.00
(in)
Depth: 7.00
(in)
Shipping: Calculated at Checkout
GTIN: 679523686161
Mounting Style: DIN Rail / Panel Mount
Current Rating: 30A AC-3 / 65A AC-1
Material: Industrial Grade Plastics and Metal Contacts
Manufacturer: A -B
Enclosure Type: 55A Max at 600V AC
Part Number: 100-C30*00
Series: 100-C
Shelf: K-4
Model: 100-C30*00
Coil Voltage: Variable (see catalog number)
Horsepower: 10 HP @ 230V / 20 HP @ 460V
MPN: 100-C30*00
Type: Contactor
