X2nd Turret Live Tooling: false
X4th Axis: false
X5th Axis: false
Additional Machine Specs: Pallet Change Time: 4.7 seconds
Max Spindle Torque: 90 ft-lb @ 2,000 rpm
Dual Pallet / Fixture Stations (180°)
B Axis: false
C Axis: false
Chip To Chip Time: 4.8
Control Make Model: Haas CNC Control
Coolant Type S: Thru-Spindle Coolant
Cutting Feed Rate: 833
Live Milling Thru Spindle Coolant: false
Live Tooling Milling: false
Max Table Pallet Load: 700.0
Max Tool Diameter: 3.0
Max Tool Length: 16.0
Max Tool Weight: 12.0
Number Of Pallets: 2.0
Programmable Tailstock: false
Rapid Traverse: 1000
Rotary Table Trunnion: None
Single Turret: false
Single Turret Live Tooling: false
Spindle Motor: 30
Spindle Speed: 8100.0
Spindle Taper Type: 40 Taper
Sub Spindle: false
Tailstock: false
Tool Changer Type: None
Tool Change Time: 2.2
Tool Magazine Capacity: 24.1
Twin Turret: false
Vertical Table Pallet Size: 20" x 12.75"
X Travel: 20.0
Y Axis: false
Y Travel: 14.0
Z Travel: 20.0
