USED 2017 HAAS DM-2

2017 Haas DM-2 vertical machining center featuring a 10,000 RPM CAT 40 spindle and Wireless Intuitive Probing System (WIPS), designed for high-speed, precision machining in a compact footprint. The DM-2 offers 28" x 16" x 15.5" travels with a 36" x 15.5" table, making it ideal for shops running smaller parts, aluminum, or tight-tolerance components.

This machine is equipped with an 18+1 side-mount tool changer and Haas CNC control, delivering fast tool changes and user-friendly programming. Rapids up to 1,200 IPM allow for efficient cycle times, while the 15 HP vector drive spindle provides consistent power across a wide range of applications.

With approximately 6,152 cutting hours and 6,902 cycle start hours, this unit shows relatively low spindle usage compared to total power-on time, indicating light-to-moderate production use. The inclusion of WIPS probing enhances setup efficiency, reduces operator intervention, and improves accuracy for repeat jobs.

Ideal for job shops, prototyping environments, or production of smaller components, this Haas DM-2 offers a strong combination of speed, precision, and reliability in a space-efficient package.

Equipped with:

Also available:

All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer’s responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase.

X-Axis Travel: 28.0"
Y-Axis Travel: 16.0"
Z-Axis Travel: 15.5"
Table Size: 36.0" x 15.5"
Max Table Load: 750 lbs
Spindle Taper: CAT 40
Spindle Speed: 10,000 RPM
Spindle Motor: 15 HP (vector drive)
Rapid Traverse (X/Y): 1,200 IPM
Rapid Traverse (Z): 1,200 IPM
Voltage: 220V
Phase: 3 Phase
Full Load: 70 Amps
Date of MFG: 10/2017
