USED 2013 LVD STRIPPIT VT 30 1525

60" X 98.4" Capacity with Fanuc 18iPB CNC Control, 40 Station Turret & 3 Programmable Clamps.

LVD Strippit VT 30 1525 CNC Turret Punch (2013)

Workpiece Size: 60” X 98.4” w/ Repo 60” X 196.8”
Material Thickness: .250”
Punching Accuracy: +- .004
Tonnage: 30 Metric Tons
Clamps: 3 Programmable
One Turret Station Change Time: 0.7 Sec.
Axis Traverse Speed: Up to 4724 IPM Combined
Maximum Hit Rate at: .08” Working Stroke
.039” Feed Rate: Up to 1000 HPM
1.000” Feed Rate: Up To 440 HP
Marking Stroke: Up To 1700 SPM
Turret Configuration Thin Turret: 40 Station
32: = 1.25”
4: = 2.0”
4: = 3.5”
4: = 3.5” Auto Index

60" X 98.4" Capacity,
Fanuc 180iP CNC Control
40 Station Turret 3 Programmable Clamps.
