| Swing | 16" | 406.4 mm |
| Machining Length | 48" | 1,219.2 mm |
| # Axis | 2 | 2 |
| Chuck Size | 8" | 203.2 mm |
| Bar Capacity | 2" | 50.8 mm |
| Power | 10 hp | 7.5 kW |
| Max RPM | 3,000 RPM | 3,000 RPM |
| Turning Dia | 16" | 406.4 mm |
| Control | CNC (HAAS) | CNC (HAAS) |
| Dimensions | 111" x 71" x 83" | 111" x 71" x 83" |
| Weight | 5,900 LBS | 5,900 LBS |
Bar Capacity: 2"
Chuck Size: 8"
Spindle Speed: 3000 RPM
Spindle Motor: 10 HP
X Axis Travel: 8"
Z Axis Travel: 48"
Rapid Rate Z Axis: 450 IPM
Rapid Rate X Axis: 450 IPM
Max Turning Dia: 16"
Max Turning Length: 48"
Max Swing: 16"
Spindle Nose A2-5
Max Torque 108 ft-lbf @ 355 rpm
Dimensions: 111" x 71" x 83"
Weight: 5,900 LBS
