USED 2013 MORI SEIKI NT-4300DCG/1500SZ
Overview
Description
The NT series models are ultimate integrated mill turn centers combining milling performance of horizontal machining centers and turning capability of CNC lathes with DMG MORI original cutting-edge technologies. The original technologies, DCG (Driven at the Center of Gravity), DDM (Direct Drive Motor), ORC (Octagonal Ram Construction), allow high-speed, high-precision machining, which contributes to high productivity.
The NT 4300 DCG, with a standard chuck size of 12 inches, offers two types of distances between centers of 1,000 mm and 1,500 mm. Various specifications including the Right Spindle and the Turret 2 specifications are available.
Specifications
| # Axis | 9 | 9 |
|---|---|---|
| Swing | 28.7" | 728.98 mm |
| Machining Length | 59" | 1,498.6 mm |
| Chuck Size | 15" | 381 mm |
| Bar Capacity | 3.5" | 88.9 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 3,000 RPM | 3,000 RPM |
| Turning Dia | 25.9" | 657.86 mm |
| Tailstock | No | No |
| Control | CNC (Fanuc F31iA5) | CNC (Fanuc F31iA5) |
| Weight | 59,000# | 59,000# |
Specifications:
Maximum Workpiece Swing Diameter mm(in.): 730(28.74)
Swing Over Cross Slide:
- mm(in.) 730(28.74)
- (turret2) mm(in.) 400(15.75)
Maximum Turning Diameter:
- (tool spindle Capto C6) mm(in.) 660(25.98)
- (turret2) mm(in.) 350(13.78)
Maximum Turning Length mm(in.): 1,542(60.71)
Bar Work Capacity mm(in.): 80(3.15)
Maximum Distance Between Centers mm(in.): 1,862(73.31)
Y-axis Travel mm(in.): ±210(8.27)
X1-axis Travel(tool spindle) mm(in.): 750(29.53)
Z1-axis Travel(tool spindle) mm(in.): 1,550(61.02)+100(3.94)
X2-axis Travel(turret 2) mm(in.): 195(7.68)
Z2-axis Travel(turret 2) mm(in.): 1,525(60.04)
B-axis Rotation Range(tool spindle) deg: ±120
Maximum Spindle Speed min-1: 4,000
Type of Spindle Nose: JIS A2-8
Through-Spindle Hole Diameter mm(in.): 91(3.58)
Minimum Spindle Indexing Increment deg: 0.0001
Spindle Bearing Inner Diameter mm(in.): 140(5.51)
Number of Tool Stations Tools: 1
B-axis Indexing Time: sec 0.65/90 degrees
B-axis Indexing Time [full indexing]: sec 0.4/90 degrees
Minimum B-axis Indexing Increment deg: 1
Minimum B-axis Indexing Increment [full indexing] deg: 0.0001
Tool Spindle Coupling Indexing Angle deg: 7.5
Maximum Spindle Speed min-1: 12,000
Number of Tool Stations Tools: 12
Shank Height for square Tool mm(in.): 25(0.98)
Diameter of Boring Bar Shank Part (Maximum) mm(in.): 50(1.97)
Turret Indexing Time(1-station) sec: 0.28
Maximum Rotary Tool Spindle Speed min-1: [6,000]
Equipped With
Fanuc 31iA5 Control
Full B-Axis Milling Head
Live Tooling on Turret
15" SMW 3-Jaw Chuck
Scale Feedback on X & Xi
Dual Ball Screws on X
Chip Blaster GV2-80 High Pressure Coolant
Chip Conveyor
Flood Coolant System
Renishaw Probe
Tool Presetter
Assorted CAPTO 6 Tools
100-Tool ATC
Hobbing Software
Transformer
Daikin Chiller
