The GLS-3000YS is a high-performance CNC turning center built for manufacturers who need more than just turning capability. Designed with a Y-axis, live tooling, and sub-spindle, this machine is ideal for shops looking to complete complex parts in a single setup while reducing cycle times and improving overall productivity. With its ability to handle turning, milling, drilling, and off-center machining operations, the GLS-3000YS offers the flexibility required for today’s demanding multitasking applications.
At the core of the machine is a powerful FANUC-controlled platform, paired with a 3,500 RPM main spindle, 5,000 RPM sub-spindle, and a 12-station live servo turret capable of 6,000 RPM live tooling performance. The addition of 100 mm Y-axis travel expands the machine’s capability beyond traditional turning, allowing for more intricate part features, secondary milling operations, and improved machining versatility. A full C-axis with disk brake on the main spindle further enhances precision for indexed and interpolated machining applications.
Engineered for stability and repeatability, the GLS-3000YS features linear guideways, FANUC AC servo motors with absolute encoders, and a direct belt-driven spindle system that delivers smooth cutting performance and dependable accuracy. The machine is also equipped with a 10-inch big-bore power chuck, 2-inch bar capacity on the sub-spindle, and a high-pressure coolant system, making it well suited for a wide range of production environments and part geometries.
| Max Swing Diameter | 760 mm | 29.921" |
| Swing Over Saddle | 450 mm | 17.717" |
| Max Turning Diameter | 400 mm | 15.748" |
| Max Turning Length | 680 mm | 26.772" |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 78 mm | 3.0709" |
| Hole Through Spindle | 90 mm | 3.5433" |
| Hydraulic Cylinder | 10" | 254 mm |
| Spindle Nose | A2-8 | A2-8 |
| Spindle Speed | 3,500 RPM | 3,500 RPM |
| Live Tooling Stations | 12 | 12 |
| OD Tool Shank Size (Live Tooling) | 1" | 25.4 mm |
| ID Tool Shank Size (Live Tooling) | 1.5" | 38.1 mm |
| Live Tooling RPM Range | 6000 RPM | 6000 RPM |
| Y-Axis Max. Turning Length | 680 mm | 26.772" |
| Y-Axis Max. Turning Dia | 400 mm | 15.748" |
| Y-Axis Travel (±) | 50 mm | 1.9685" |
| CN Control | FANUC 0I-TF PLUS | FANUC 0I-TF PLUS |
FANUC 0I-TF PLUS CONTROL WITH 15” LCD SCREEN WITH IHMI
FANUC ALPHA SPINDLE & SERVO DRIVES
FANUC AC 2
0 HP (CONT.), 25 HP (30 MIN.), 30 HP (PEAK) DUAL WINDING SPINDLE MOTOR
DUAL SPINDLE SPEED CONFIGURATION
LINEAR GUIDE WAYS
10” 3-JAW THROUGH-HOLE (78 MM) BIG-BORE POWER CHUCK INCLUDING ONE SET OF SOFT JAWS & ONE SET OF HARD JAWS)
SUB SPINDLE RPM: 5,000 RPM WITH 2” (51 MM) BAR CAPACITY
SUB SPINDLE CHUCK 8” 3-JAW 2” (51 MM) BAR CAPACITY POWER CHUCK INCLUDING ONE SET OF SOFT JAWS AND ONE SET OF HARD JAWS
RENISHAW MANUAL TOOL SETTER (HPRA) FOR MAIN & SUB SPINDLE
RENISHAW HPRA REMOVABLE PROGRAMMABLE IN-MACHINE TOOL SETTER FOR MAIN SPINDLE
PARTS CATCHER AND EXTERNAL PARTS CONVEYOR
PNEUMATIC PARTS EJECTOR WITH COOLANT THROUGH SUB-SPINDLE
SMART CHUCK SENSOR FOR MAIN & SUB-SPINDLE
X/Z AXIS FANUC AC 3.6 HP SERVO MOTOR WITH ABSOLUTE ENCODER
Y AXIS TRAVEL 3.93” (100 MM) WITH FANUC AC 3.6 HP SERVO MOTOR
12 STATION LIVE SERVO TURRET (7.5 HP, 6,000 RPM, ER-32) WITH 1” OD AND 1-1/2” ID TOOLING SHANK
STANDARD TOOL HOLDER AND SLEEVES PACKAGE INCLUDING:
1 X 0° LIVE TOOL HOLDERS (COLLET: ER-32
1 X 90° LIVE TOOL HOLDERS (COLLET: ER-32)
FULL CF AXIS WITH DISK BRAKE ON MAIN SPINDLE
GRUNDFOS 94 PSI HIGH PRESSURE COOLANT PUMP (MTH 2-50/5)
ROLL-OUT COOLANT TANK
CHIP CONVEYOR WITH AUTO TIMER, HINGE TYPE, RIGHT DISCHARGE, DISCHARGE HEIGHT: 47”
OIL SKIMMER
TOOLBOX WITH EMERGENCY MAINTENANCE ELECTRICAL PART PACKAGE
FULLY ENCLOSED GUARDING
DOOR INTERLOCK
HYDRAULIC PRESSURE SAFETY SWITCH
PROGRAM PROTECT
CHUCK CLAMP/UNCLAMP CONFIRMATION
THREE COLOR OPERATION STATUS SIGNAL LIGHT TOWER
OPERATION AND MAINTENANCE MANUALS
