USED SAFELINE ADVANTAGE PROFILE LS

🏭 Manufacturer & Model Information

Brand: Safeline (by Mettler-Toledo)

Model: Advantage Profile LS

Condition: Unused

Conveyor: PIUS SL2000 with 2438mm system length

Interface: EtherNet/IP, 1-Port, IP66 Rated

Mounting Style: Base Mount, Module on Side

📄 Product Description
This unused Safeline Advantage Profile LS Metal Detector system offers high-performance contaminant detection using multi-simultaneous frequencies, ideal for packaged food, pharmaceuticals, and industrial QA. Built from 304 stainless steel with a bead-blast finish, it features a 200mm x 125mm aperture, IP65 ingress protection, and is mounted on a flat-level conveyor system.
The integrated PIUS SL2000 conveyor, also IP65 rated, includes a white modular Intralox belt and a light-duty air blast reject system directing product to a stainless steel locking bin located at the front HMI side. With hygienic tubular construction, this system is optimized for reliability, sanitation, and precision in medium-duty processing environments.

⚙️ Technical Specifications

Feature
Specification

Aperture Size
200mm W x 125mm H (7.87" x 4.92")

Case Material & Finish
SS304 Bead-Blasted

Conveyor Model
PIUS SL2000

System Length
2438mm (Custom: 1801–2500mm Range)

Conveyor Belt Width
150mm

Belt Type
White Modular Intralox (Non-Quick Release)

Belt Height
800mm

Orientation
Level / Flat

Mounting
Leveling Pads ±50mm

Operating Frequency
Multi Simultaneous Frequencies

Fieldbus Interface
EtherNet/IP, 1-Port, IP66 Rated

Ingress Protection
IP65 (Detector & Conveyor)

Reject Type
Light Duty Air Blast (0.5kg)

Reject Bin
All Stainless Steel, Manually Locking

Reject Bin Location
Front (HMI Side)

Hygiene Rating
Standard Tubular Construction

Product Weight
15kg

PVR (Product Validation Reject)
No

🧪 Applications
This Safeline system is optimized for:

Food inspection (packaged, raw, or processed)

Nutraceutical manufacturing

Pharmaceutical QA lines

Dairy and beverage packaging

Bakery and pastry production

Fresh meat and seafood inspection

Lightweight industrial part inspection

Cartoned dry goods QA

Blister and bottle pack checks

Frozen or ready-to-eat meals

📦 Typical Products Used For

Snack bags and bar packs

Bottled supplements and pharma goods

Carton-packed dairy or yogurt

Ready meals in trays

Bakery rolls and pastries

Packaged poultry or seafood

Powder containers

Plastic molded components

Packaged dry foods

Blister packs
