Equipment Included
(2) Metso Nordberg C80 Jaw Crusher
(2) Dual Impact Crusher w/ Screen Unit, 350HP, 575V, 1790 RPM
(2) Terex Jacques Apron Feeder D3C
(2) Metso 9-Cell Rougher Flotation Circuit RCS 5
(9) Conveyor Units
(2) Eriez Suspended Magnet MC-2 SE-7330
(2) Joest Vibrating Screen SUE 1220 x 2450 w/ 3.6 kW Motor
(2) Falcon SB400 Batch Gravity Concentrator
(2) Falcon Small Batch Gravity Concentrator
(5) Sizetec Step Deck Screen SDS38-6MV-5
(1) APPL 34 SCFM Air Compressor CP18-1112
(3) Warman Pump Skids, 40HP, 575V, 1770 RPM
(4) Metso Tailing Pump Skid w/ Warman Pump & Motor
(1) Tailing Thickener Tank w/ Rake
(1) Transmin Low & High pH Flocculant System w/ Storage Tanks
(5) Gekko Reagent Mixing/Storage Tank Skids
(1) Delta Multi-Purpose Tank w/ Ladder & Catwalk
(1) Ingersoll-Rand Heatless Desiccant Dryer HL500
(2) Ingersoll-Rand Compressor R75I-A125, 100HP, 455 CFM
(2) Regrind Ball Mill w/ Gear Reducer & Motor
(1) Concentrate Filter Assembly
(3) Metso/Outotec Leach Residue Tank
(2) Metso/Outotec Larox - PF Vertical Filter Press
(1) Large Flotation Column
(3) 2000 Amp Resin Rectifier
(6) Stainless Steel Mixing Tank Skids
(15) Electrical Seacan w. MCC's and VFD's
(1) Donaldson Torit Dust Collector w/ 22PLR New York Blower, 12000 ACFM
(1) Allen Bradley Powerflex 755 AC Drive
(1) Potable & Hot Water Shower Skid
Equipment Excluded
(1) Metso Nordberg C100 Primary Jaw Crusher
(2) Tertiary Screens
(2) Primary Ball Mill & Cyclones
Oxygen Systems
