Hazardous Area Rating: EEx ia IIC
BAS EEx Certification Number: Ex92C2382
Maximum Ambient Temperature: 60 C
Supply Voltage: 20 to 30 VDC via Power Rail or Terminals
Input Type: Strain Gauge Bridge Input
Output Type: Analog Current Output
Output Signal: 4 to 20 mA
Maximum Voltage Um: 250 V Terminals 23 24 and Power Rail
Voltage Um Terminals 16 17 18: 40 V
Maximum Output Voltage Umax: 17.6 V
Maximum Output Current Imax: 314 mA
Mounting Type: DIN Rail Mount
