– Blade Diameter: 22″
– Round Cutting Capacity (90°): 7.9″
– Square Cutting Capacity (90°): 6.7″ x 6.7″
– Minimum Cut Size (Round): 0.4″
– Minimum Cut Size (Flat): 0.4″ x 0.4″
– Main Drive Motor: 34.9 HP
– Max Blade Speed: 3,400 RPM
– Single Stroke Feed Length: 39.4″
– Max Feed Rate: 78.7 in/sec
Equipped With:
– Automatic Bar Loader
– Conveyor Outfeed
– Infeed Table System
– Servo Feed System
– Servo Clamping System
– NC / PLC Control
Dimensions:
Saw: 6’6”x6’x7’9” – 4,000lbs.
Conveyor: 14′ x 2’2” x 3′ – 500lbs.
Dust Collector: 3’6′ ‘x2’7” x 7’10” – 1000lbs
Material rack: 12’10” x 6’7” x 3’10” – 1000lbs.
