2005 HAAS SL-30T CNC
Haas Coldfire Control
3.5" floppy drive
Tailstock
12 Station Bolt on Turret
Chip Conveyor
Coolant Tank and Pump
Samchully HS-10 inch 3 Jaw power chuck
Machine Voltage: 208
Machine KVA: 30
| CNC Control | Haas CNC Control | Haas CNC Control |
| CNC Control Type | Haas | Haas |
| # of Axes | 2 | 2 |
| Swing | 30" | 762 mm |
| Turning Dia | 17" | 431.8 mm |
| Center Distance | 39" | 990.6 mm |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 3" | 76.2 mm |
| X-axis Travel | 11.3" | 287.02 mm |
| Z-axis Travel | 34" | 863.6 mm |
| Rapid Traverse Rate (X/Y/Z) | 710 ipm | 710 ipm |
| Spindle Nose | A2-6 | A2-6 |
| Spindle Speed (rpm) | 3,400 RPM | 3,400 RPM |
| Spindle Motor (hp) | 30 hp | 22.4 kW |
| Tailstock | Yes | Yes |
| Live Tooling | No | No |
| Turret Capacity | 12 | 12 |
| Machine Weight | 14,500 lb | 6,577.1 kg |
| Weight | 14500 | 14500 |
