| Swing | 26" | 660.4 mm |
| Power | 3 hp | 2.2 kW |
| RPM | 1,130 RPM | 1,130 RPM |
CAPACITY: 24" SWING
SPINDLE SPEEDS 95 - 1,130 RPM 6 SELECTIONS
POWER FEED ON SPINDLE .004-.008-.012-.020
QUILL DIA. 2.550"
NO. 4 MT SPINDLE
22" MAX WORK UNDER SPINDLE
20" X 22" T-SLOTTED TABLE
COOLANT SYSTEM
MOTOR: 3 H.P
220VOLTS 3 PH
APPROX 2500LBS
OVERALL 52"L x 32" W x 8'4"H
