Northtech NT 12‑1300RRP Three Head 51″ Wide Belt Sander

This is a very robust machine. With its larger diameter heads (12″ on first and second) and larger motors (40/40/30), it’s capable of powering thru material with ease.
***This machine is also available in other working widths.

Working Width:  51″
Sanding Heads:  (3)
(1) 12″ 70 durometer spiral fluted roller
(1) 12″ 65 durometer spiral fluted roller
(1) 3-1/4” Pad
(1) 12″ 70 durometer spiral fluted roller
(1) 12″ 65 durometer spiral fluted roller
(1) 3-1/4” Pad
Main Spindle Motor:  40HP / 40HP / 30HP
Feed Motor:  5HP with Inverter
Table Elevation Motor (PLC Touch Screen):  1HP
Configuration:  Rubber Roller-Rubber Roller-Pad
Size Of Sanding Belt:  53″ x 103″
Feed Speed:  15 ~ 60 FPM via inverter
Table Height: 37″
Table Lift: 4.75″ by PLC Touch Screen
Belt Cleaner:  (3) Full Coverage Oscillating Cleaners
(1) Brush Roller, 1HP
Voltage:  230V / 460V, 3-Phase
Weight Net / Gross:  15,875 lbs. / 16,500 lbs.
Dimensions:  102″L x 86″W x 93″H
Warranty is one-year parts.
All machines tested stateside, ensuring trouble-free start-up.
Machine Hp. = 117 hp.
Voltage/ Freq. = 230/460 Volt 60Hz
Phase = 3 Phase
Amp Requirement = 274/137 Amps
Configuration = Roller, Roller, Pad
1st Head = 40 Hp. 12” Spiral Fluted 70 D
2nd Head = 40 Hp. 12” Spiral Fluted 65 D
3rd Head = 30 Hp. 3-1/4” Pad
Brush Motor Hp. = 1 Hp.
Feed Hp. = 5 Hp.
Feed System = 53” Rubber Feed Mat
Drive System = Gear Box Inverter Controlled
Feed Speed = 15 – 60 FPM
Variable Speed = Inverter Controlled
Elevation Hp. = 1 Hp.
Elevation Sys. = (4) Post Jack Screw
Elevation Style = Auto Touch Screen Control
Total Hp. = 117 Hp.
Electronics = CE Approved Components
Dual Voltage = 230/460 Volt
Control Voltage = 230 Volt
Programmable = Elevation
Touch Screen = 8” Digital Touch Screen
Min. Length = 20”
Max. Width = 52”
Min. Thickness = 1/4”
Max. Thickness = 4-3/4”
No. of Heads = 3
Sandpaper Size = 53” x 103”
Platen Specs. = 4” x 54” with 8” Graphite
1st Belt Speed = 5000 FPM
2nd Belt Speed = 5000 FPM
3rd Belt Speed = 3000 FPM
Oscillation Sty = Pneumatic Controlled
Oscillation Rte = 20 Cycles/Minute
Oscillation Trv = 1/2”
Cleaning System = Oscillating Jet Blow Off
Tracking Style = Pneumatic Dust Proof Eye
Tension Style = Pneumatic
Dust Collection = (14) 5” @ 9534 CFM
Dust Port Out = 5”
Digital Display = Touch Screen 8”
Conveyor = Seamless
Powered Rollers = (12) Hold Down Rollers
Idle Rollers = (12) Hold Down Rollers
Pressure Shoes = (3) Sets
Hold Down Style = Spring Loaded Pressure Shoes
Recommended CFM = 570 nl/min
Emergency Stop = (1) Push Putton (2) Bars
Brake System = (3) Pneumatic Dual Caliper Dis
Frame Const. = 1” Steel Construction
Measure Meth. = Digital
Decible Rating = 79 dB
Net Weight = 15,875 Lbs.
Gross Weight = 16,500 Lbs.
Machine Dims. = 110” x 67” x 73”
Packaging Dims = 120” x 91” x 94”
