Northtech NT 1300RC‑MT Dual Head 51″ Wide Belt Sander
Overview
Description
This is a very robust machine. With its larger diameter heads and larger motors, it is capable of powering thru material with ease.
***This machine is also available in other working widths.
Specifications
Voltage/ Freq. = 460 Volt 60Hz
Phase = 3 Phase
Configuration = Roller, Combination Head
1st Head = 9.5” Steel Drum 12900 RPM
2nd Head = 8.5” Rubber 2.5” Platen 13
Brush Motor Hp. = 1 Hp.
Feed Hp. = 4 Hp.
Feed System = 51” Rubber Feed Mat
Feed Speed = 15 – 110 FPM
Variable Speed = Inverter Controlled
Elevation Hp. = 3/4 Hp.
Elevation Sys. = (4) Post Jack Screw
Total Hp. = 77 Hp.
Electronics = UL Approved Components
Control Voltage = 110 Volt
Programmable = Elevation
Operator Panel = Fixed
Min. Length = 22-3/4”
Min. Thickness = .11”
Max. Thickness = 4.34”
Sandpaper Size = 53” x 86”
Platen Specs. = 2-1/2” x 52-3/4”
Roller Type = Solid Rubber
1st Belt Speed = 4820 FPM
2nd Belt Speed = 4260 FPM
Tracking Style = Pneumatic W/ Photo Eye
Tension Style = Pneumatic
Dust Collection = (2) 8” (1) 5” 4170 Total CFM
Idle Rollers = (6) Idle Rollers
Emergency Stop = Push Button
Brake System = Single Caliper Disk Brake
Frame Const. = 1/2” Steel Construction
Infeed Table = 13” x 51-3/4” Infeed Table
Outfeed Table = 8” x 51-3/4” Outfeed Table
Decible Rating = 82 dB
Machine Dims. = 80” x 104” x 86”
