Northtech NT CutMate 2800 Series Single Knife Veneer Guillotine

Thanks to a partnership with SAVI Industri A/S–boasting the top market share in U.S.A. and UK for veneer guillotines–NT CutMate 2800 Series Single Knife Veneer Guillotines are constructed to maximize operator safety and comfort.  All INNOVATOR guillotines employ complete hydraulic control of both knives and pack beam. The pressure of both knife and pack beam is adjustable. Various materials including veneers, paper, plastics and so on can be cut. When coupled with the INNOVATOR Double-Sided Veneer Glue Applicator (GlueMate 700) & Crossfeed Veneer Splicer (UltiMate series), the perfect gluing and jointing result is accomplished with high production efficiency.

60 mm knife cylinder
Green cutting indicator
150 mm wide pack beam
JAPAN YUKEN hydraulic system
With European safety standards
JAPAN MITSUBISHI PLC control system
Rigid welded machine body for stable movement
Safety light barrier of knife and pack beam in front
Magnetic scale for accurate linear position measurement of the fence
Adjustable pressure with hydraulic knife and pack beam for all kinds of veneers
“Safety locker” at the front end of the knife beam (unique and only in innovator’s guillotines)
Special designed “emergency valve” for knife to minimize operational danger caused by mechanical faults
Extra safety valve of knife beam with additional safety knife protective cylinder to keep off any drop of knife
Two-hand operation of the knife and pack beam ： no movement of the pack beam against the veneer pack made immediately when one push button is released
SECOND-CUT Technology for thick or especially hard species of veneers cutting available By switching knife beam to second-cut mode, a thin clip of approx. 1 mm is cut off from the veneer pack after the first trim. This unique feature which can only be found in all INNOVATOR’s guillotines is necessary when working with thick or especially hard species of veneers.
