specifications from website should be verified
Swing over bed
3.50"
4.75"
6.75"
Swing over carriage
1.75"
3.0"
5.0"
Distance between centers
8.00"
17.00"
17.00"
Cross Slide Travel
2.25"
4.25"
4.25"
Tail stock spindle travel
1.50"
1.50"
1.50"
Resolution
.0001"
.0001"
.0001"
Backlash
.003" Max.
.003" Max.
.003"
Hole thru Spindle
0.405"
0.405"
0.405"
Spindle Nose Thread
3/4"-16 TPI
3/4"-16 TPI
3/4"-16 TPI
Tail Stock Spindle Taper
#0 Morse
#0 Morse
#0 Morse
Spindle Speed Range
75-2800 RPM
75-2800 RPM
75-2800 RPM
Spindle Nose Taper
#1 Morse
#1 Morse
#1 Morse
Spindle Motor
1/2 HP DC
1/2 HP DC
1/2 HP DC
Length Overall
23.5"
32.5"
32.5"
Width Overall
10.5"
10.5"
10.5"
Height Overall
8.5"
8.5"
10.5"
Weight
36 lbs
45 lbs
45 lbs
Included Accessories:
3/8" Tailstock Chuck & Key
Face Plate
Dog & Screw
#0 and #1 Morse Centers
5/32" and 3/32" Hex Keys
Tool Post (Rocker style tool post with extended lathe)
2.5" OD 3 Jaw Chuck (3.125"OD Chuck with extended lathe)
NEW PRICE APROX $4,000.00
https://www.microkinetics.com/index.php?page=cnclathe
