USED 2011 HOMMA HMT 8/10 GTN

Fanuc-30i CNC Control System
Automatic Milling Tool Changer ISO 60 : 10 – ISO 50 : 10
Tilt Attachment ISO 50 A & B axis Control
Offset Snout ISO 50 Offset Value 225 mm
3 x Turning Heads
Automatic Attachment Changing Function for 10 attachments
Coolant Unit (Including Air Blow Function) High & Low Pressure Switching Type
(C-Axis) CNC Vertical Boring Mill Table 8000 mm dia.
Operator Platform
Chip Conveyors Hinge Belt Type
Closed Loop Control System X, Y, Z, W, A, C Axis
Tool Length Measurement: For Turning Tools
Operator Platform : Fixed to Both Side Column Base
Pendant Control Box : Up/Down Right/Left By Electric Powered

Manufacturer: Homma
Model: HMT-8/10 GTN
Year: 2011
Condition: Used
Stock Number: 10913
Table diameter: 8,000 mm
Swing: 10,000 mm
Turning height: 7,200 mm
Table capacity: 250 Ton
Live spindle speed: 1,600 rpm
Gantry travel: 15,000 mm
Z axis travel: 3,000 mm
X axis travel: +7,000 mm - 8,000 mm
Y axis travel: 11,300 mm
W axis travel: 4,200 mm
Distance between columns: 10,000 mm
Table indexing minimum increment: 0.0001 Degree
Table drive system: Double Worm, Double Pinion Gear Drive
Rapid traverse rate table: 180 deg/min
Feed rate of table: 1 - 180 deg.min
Feed rate x axis: 1 - 5,000 mm/min
Table clamping force: 49,000 Nm - 5,000 kg/m
Table position detector: Heidenhain 786 Rotary Encoder
Index control system: Hybrid Controlled Closed Loop
Table clamping method: Hydraulic Disc Brakes
Rapid traverse x axis: 8,000 mm/min
Drive system: Precision Rack & Pinion
X axis position detector: Heidenhain Optical C Scale
Main head ram type: 650 x 650 mm
Spindle drive capacity: AC 100 kW
Spindle diameter (snout): 220 mm
Milling spindle taper: ISO 60
Machine height above floor: 16,000 mm
Floor space required: 28 x 20 m
