USED 2025 TOSHULIN SKIQ-16
Overview
Description
Machine Completely Rebuild & Retrofitted in 2025 by the OEM. Condition: NewSiemens Sinumerik One CNC ControlLive spindleFull - way positioning C axis (boring, milling with continuous controllable driving tools)15 Tool (Driven) PositionsFull machine coveringChip conveyorCooling deviceCoolant Through Spindle - 20 barFull machine documentation
Specifications
Manufacturer: TOS HULIN
Model: SKIQ 16
Year: 2025
Condition: Used
Stock Number: 11177
Table diameter: 1,600 mm
Swing: 1,800 mm
Turning height: 1,275 mm
Table capacity: 12 Ton
Table turn speed: 200 rpm
Live spindle speed: 3,300 mm
Z axis travel: 1,000 mm
C axis: 360°
Ram size: 180 x 220 mm
Main drive: 60 kW
Live spindle motor: 19.5 kW
Working feed: 4,000 mm/min
Rapid feeds: 10 m/min
Machine weight: 27.2 Ton
Machine dimensions: 5.7 x 7 x 5.9 m
