650 Ton X 16’ Hydraulic Press Brake with Manual Push Button and Foot Pedal Controls, 10’ Between Housings, 4’ Horn on LH side and Light Curtains.
| Tonnage | 650 T | 589.671 t |
| Overall Length | 16' | 4.9 m |
650 Ton X 16’ Hydraulic Press Brake with Manual Push Button and Foot Pedal Controls, 10’ Between Housings, 4’ Horn on LH side and Light Curtains.
GENERAL SPECIFICATIONS
Tonnage: 650 TONS
OA Length: 16’
Between Housings: 10’
Between Housings: 4”
Stroke: 26”
Dimensions: 16' X 8' X 15'H
Weight: 87,000 LBS
Bed Width: 12"
Throat Depth: 16"
Capacity: 3/4" X 10'
Stroke Length: 26"
Full Tonnage: 16 IPM
Half Tonnage: 32 IPM
Rapid Advance: 64 IPM
Return Speed: 64 IPM
INCLUDES: Manual Push Button and Foot Pedal Controls, 10’ Between Housings, 4’ Horn on LH side, 300 Gallon Hydraulic Capacity, Dual 25 HP Hydraulic Drives and Light Curtains.
