| Type | All Electric | All Electric |
| Clamping Force Tonnage | 110 T | 99.79 t |
| Shot Volume (PS) | 9 oz | 255.1 g |
| Tie Bar Distance H | 16.93" | 430.02 mm |
| Tie Bar Distance V | 14.17" | 359.92 mm |
| Platen Dimension H | 25" | 635 mm |
| Platen Dimension V | 24" | 609.6 mm |
| Clamp Stroke | 28.54" | 724.92 mm |
| Mold Height Min | 9.84" | 249.94 mm |
| Ejector Stroke | 5.91" | 150.11 mm |
| Control | CNC (Procan Alpha) | CNC (Procan Alpha) |
