| Table-W | 12" | 304.8 mm |
| Table-L | 30" | 762 mm |
| Horz/Vert | Horz | Horz |
| Power | 5 hp | 3.7 kW |
| Control | CNC (K O Leematic 7000) | CNC (K O Leematic 7000) |
K.O. LEEMATIC 7000 CNC CONTROL
12" X 30" MAXIMUM CAPACITY WITH
10" X 24" SUBURBAN PERMANENT MAGNETIC CHUCK
12" DIAMETER GRINDING WHEEL CAPACITY
VARIABLE SPEED SPINDLE WITH AC TECH
MODEL SCF SERIES INVERTER
SIMPSON DIGITAL RPM & AMP DISPLAY
15-3/4" MAXIMUM SPINDLE CENTER TO TOP OF TABLE
AUTOMATIC OVER THE WHEEL DRESSER
ABB 5 H.P. SPINDLE MOTOR
BALDOR 28 IN/LB DC MOTORS & DRIVES FOR Y & Z AXIS
2.6 KW HYDRAULIC UNIT
.025 KW COOLANT PUMP
MACHINE WIRED 460 VOLTS/3PHASE
AVAILABLE OPTIONAL EQUIPMENT:
12" X 24" ELECTROMAGNETIC CHUCK WITH VARIABLE
HOLD & AUTOMATIC DEMAG CONTROLLER
