This is a refurbished Agilent 1100 G1367A Well-Plate Sampler.
The Agilent 1100 G1367A WPALS enhances system flexibility and accelerates injection cycles. It provides the convenience of control through either a handheld controller or a computer running ChemStation. This system is adaptable and user-friendly, especially when managing diverse sample containers.
Specifications:
Injection Range: 0.1 – 100 µl in 0.1 µl increments Up to 1500 µl with multiple draw (hardware modification required)
Precision: Typically, <0.5% RSD of peak areas from 5 – 100 µl, Typically <1 % RSD from 1 – 5 µl
Sample Viscosity Range: 0.2 – 5 cp
Sample Capacity: 2 x well-plates (MTP) + 10 x 2 ml vials
100 x 2 ml in one tray
40 x 2 ml in half tray
Ambient operating temperature: 4 – 55°C
Ambient non-operating temp: -40 – 70°C
Humidity (Non-condensing): <95 %, at 25 – 40°C
Operating altitude: Up to 6500 ft
Non-operating altitude: Up to 14950 ft
Weight: 35 lbs. (15.5 kg)
Dimensions: 13.5″ W x 17″ D x 8″ H (35 x 44 x 21 cm)
Line voltage: 100-240 VAC, ±10%
Line frequency: 50/60 Hz, ±5%
Power consumption (apparent): 300 VA Maximum
Power consumption (active):200 W Maximum
Includes:
Agilent 1100 G1367A Well-Plate Sampler
In-House Warranty Coverage
Options:
Installation & Familiarization
Extended Warranty Coverage
Financing Available
