USED 1951 DENISON KC

50-Ton Denison "Long Stroke" Hydraulic Multipress | Model KCThis Denison Model KC is a heavy-duty, 50-ton C-frame hydraulic press engineered for high-force applications requiring a significant vertical work envelope. Known as the "Long Stroke" variant, this unit offers a generous 21" stroke and up to 28" of daylight, making it ideal for deep drawing, tall part assembly, and complex forming operations that standard presses cannot accommodate.Built with a rigid, over-engineered cast frame, this Multipress (S/N 50237-51) provides the stability needed for high-tonnage precision work. Its open-throat design allows for easy three-sided part access and seamless integration into existing production lines or automated cells.Technical SpecificationsManufacturer: Denison (Denison Engineering Co.)Model: KCSerial Number: 50237-51Year of Manufacture: 1951Capacity: 50 TonStroke: 21" (Long Stroke)Throat Depth: 12"Daylight: 24" (with 4" riser) or 28" (without plate)Table Dimensions: 20" x 60"Main Motor: 30 HPPower Requirements: 230/460V, 3 Phase, 60 HzApproximate Weight: 10,000 lbsKey FeaturesExtended 21" Stroke: Provides exceptional versatility for deep-draw stamping and tall assembly tasks.Large Bed Area: The 20" x 60" table provides ample room for large dies, multi-stage fixtures, or shuttle-feed systems.Massive Cast Construction: Features the legendary Denison "iron" that minimizes frame spring and ensures long-term tool alignment.Self-Contained Hydraulics: Includes a high-efficiency hydraulic system designed for continuous-duty industrial production.

* Table Dimensions: 20" x 60"
* Capacity: 50 Ton
* Stroke: 21" (Long Stroke)
* Main Motor: 30 HP
* Throat Depth: 12"
* Approximate Weight: 10,000 lbs
