USED KELLENBERGER KEL-VARIA RS 225/1000
Overview
Description
Kellenberger Kel-Varia RS 225/1000 CNC Cylindrical Grinder, (2) OD Wheels
Specifications
| Swing | 17.7" | 449.58 mm |
|---|---|---|
| Centers | 39.4" | 1,000.8 mm |
| Grinding Wheel Dia. | 20" | 508 mm |
| Dimensions | 14' x 8' x 7' | 14' x 8' x 7' |
| Weight | 11500 | 11500 |
Kellenberger Kel-Varia RS 225/1000 CNC Cylindrical Grinder
Model: KEL-VARIA RS 225/1000
Control: Kelco 90
Center Height: 8.85” (225 mm)
Max. Swing: 17.7” (450mm)
Max. Between Centers: 39.4” (1000 mm)
Grinding Length: 39.4” (1000 mm)
Weight of Workpiece: 330 lbs (150 kg)
Workhead Spindle Speed: 1220 RPM
Grinding Wheel Diameter: 19.6”
LONGITUDINAL SLIDE: Z-Axis
Travel: 45.27”” (1150 mm)
Rapid Traverse Speed: 15 m/min
Swiveling range of upper table: 9/9/7 deg.
WHEELSLIDE: X-Axis
Travel: 12.59” (320 mm)
Rapid Traverse Speed: 7.5 m/min
Workhead:
Rotational spindle speed: 8 – 800 rpm
Tailstock:
Internal taper: MT4
Retraction of sleeve: 1.96” (50 mm)
CNC Control: Kelco 90
Measuring System:
Gap Control: KEL-TOUCH
Active. Long. Positioning: Movomatic
Passive Long. Positioning: Movomatic
Approx. Dimensions: 14' x 8' x 7' (tall).
Approx. Weight: 11500 lbs
