USED 1998 KELLENBERGER KEL-VARIA RS 225/1000

Kellenberger Kel-Varia RS 225/1000 CNC Cylindrical Grinder

Model: KEL-VARIA RS 225/1000
Control: Kelco 90

Center Height: 8.85” (225 mm)
Max. Swing: 17.7” (450mm)
Max. Between Centers: 39.4” (1000 mm)
Grinding Length: 39.4” (1000 mm)
Weight of Workpiece: 330 lbs (150 kg)
Workhead Spindle Speed: 1220 RPM
Grinding Wheel Diameter: 19.6”
LONGITUDINAL SLIDE: Z-Axis
Travel: 45.27”” (1150 mm)
Rapid Traverse Speed: 15 m/min
Swiveling range of upper table: 9/9/7 deg.
WHEELSLIDE: X-Axis
Travel: 12.59” (320 mm)
Rapid Traverse Speed: 7.5 m/min
Workhead:
Rotational spindle speed: 8 – 800 rpm

Tailstock:
Internal taper: MT4
Retraction of sleeve: 1.96” (50 mm)

CNC Control: Kelco 90

Measuring System:
Gap Control: KEL-TOUCH
Active. Long. Positioning: Movomatic
Passive Long. Positioning: Movomatic
Approx. Dimensions: 14' x 8' x 7' (tall).
Approx. Weight: 11500 lbs
