| X | 80" | 2,032 mm |
| Y | 40" | 1,016 mm |
| Z | 36.2" | 919.48 mm |
| Power | 47 hp | 35 kW |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 40 | 40 |
| Taper | CT 50 | CT 50 |
| Table-W | 39.4" | 1,000.8 mm |
| Table-L | 82.7" | 2,100.6 mm |
| # Axis | 3 | 3 |
| Control | CNC (FANUC OIMF PLUS) | CNC (FANUC OIMF PLUS) |
| Dimensions | W216” xD 163” x H139.5” | W216” xD 163” x H139.5” |
| Weight | 33,000 | 33,000 |
