• Pipe range: 2” to 30” diameter (48” optional)
• Contour bevel, weld prep, mitres, saddles, holes, slots, gussets, etc.
• Chuck driven: Precise positioning, no slippage or pipe walk
• Automatic chuck height adjustment for pipe diameter range
• Automatic chuck clamping / unclamping for quick setup
• Floating chuck mechanism feature allows for cutting of bent or
“out-of-round” pipes
• Motorized In-Feed conveyor: up to 60’ length
• Rigid Gantry style construction with dual drive motion for
accurate, smooth motion
• Integrated automatic torch height sensing for precise torch
standoff from material
• Integrated fume extraction (optional)
| Cut-Width | 48" | 1,219.2 mm |
| Cut-Length | 60' | 18,288 mm |
| Plasma Power | 300 a | 300 A |
| # Plasma Torches | 2 | 2 |
| Cutting Speed | 500 ipm | |
| Rapid Traverse Speed | 1000 ipm |
