• Unitized system
• Table sizes: 5’ x 10’ up to 12’ x 45’
• Custom table sizes and configurations available
• Zoned down draft or water table
• 6” x 8” heavy duty fully machined steel gantry
• Bosch linear ways on rails and gantry
• Bosch Rexroth A/C servo drive motors with Ethercat
• Helical Agma 10 rack and pinion gears
• Ultra precision helical planetary gearboxes
• Welded and machined over-sized end trucks
• Magnetic torch breakaway
• Hypertherm HyDefinition plasma cutters
• Hypertherm Edge Connect CNC controller with ProNest
• Windows-based, 19.5” touch screen monitor
• Machitech Automatic Torch Height Control
• Full part list and electrical schematics
• On-site installation and training included
• Free lifetime remote support
| Cut-Width | 6' | 1,828.8 mm |
| Cut-Length | 12' | 3,657.6 mm |
| Plasma Power | 170 a | 170 A |
| # Plasma Torches | 2 | 2 |
| Cutting Speed | 800 ipm | |
| Rapid Traverse Speed | 1800 ipm |
