Or as low as $327.82 USD/month over 60 months
2023 Doosan HC400II CNC Horizontal Machining Center, gently used with 4-axis capability, 60-tool storage, and pallet changer. Features include 12,000 RPM spindle, 16"x16" pallet size, and only 700 spindle hours. Fully equipped with chip conveyor.
| X-Axis | 23.6" | 599.44 mm |
| Y-Axis | 22" | 558.8 mm |
| Z-Axis | 22.2" | 563.88 mm |
| # Axis | 4 | 4 |
| Power | 25 hp | 18.6 kW |
Feed Rates-
Rapid Traverse (X/Y/Z): 40 m/min / 1,575 ipm
Main Spindle-
Max Spindle Speed: 12,000 RPM
Spindle Motor: 18.5/11 kW / 25/15 hp
Max Spindle Torque: 353.4 N·m / 261 ft-lb
Spindle Taper: ISO #40 (CAT 40 / BT 40 / Big-Plus)
Pallet / Table-
Pallet Size: 400 × 400 mm / 16" × 16"
Max Workpiece Weight: 400 kg / 882 lb
Number of Pallets: 2 (APC)
B-Axis Indexing: full 4th axis
Tool Storage: 60 TOOLS
CNC Control: Doosan-Fanuc i Series
CHIP CONVEYER
FULL 4TH AXIS
ONLY 700 SPINDLE HOURS
