PLC controlled logic functioning Complete with: - Thermostatic glue control with automatic standby and temperature Indicator - Light-up LED buttons for machine operating units selection - Diagnostic system with messages for machine use and maintenance - Statistical operating data: total hours of machine use, total and partial meters of edge used • Automatic panel feeding by steel core toothed belt • 3 position infeed fence: 0-1-2 mm (according to edge thickness) • Pneumatic edge cutting shears from coil • Teflon-coated glue pot fitted with 6 electrical heating elements (4 in the glue pot, 1 in the turret and 1 inside the glue spreading roller) for uniform glue temperature. Motorized glue spreading roller. • 3 pressure rollers (1 rubber and 2 nylon) • Pneumatic End trimming unit with shears and follow-up system (front and rear edges), can be excluded from the control panel. • One motor flush trimming unit (top-bottom) 10.300 RPM with Z4 Ø 75 mm cutterblocks, WIDIA disposable knives, combined profile: straight/radius 2 mm/bevel with vertical disc copiers and numeric dials • Working table length 1.800 mm with 7 adjustable rollers and Polizene sliding fences • Front extensible support for large panels with Polizene sliding fences
| Weight | 533.00 LBS | 533.00 LBS |
Width: 80.00
(in)
Height: 52.00
(in)
Depth: 49.00
(in)
Shipping: Calculated at Checkout
