USED 2013 KOCH SPRINT PTP CLASSIC

*Video is for reference only. Not actual machine.* Koch Sprint PTP Classic - Features and Specifications Horizontal drilling station with 1 drilling spindle Drilling motor: 1.25 HP Drilling speed: 7200 RPM Max. drilling depth: 1.1" (28 mm) Drill bit mounting: ⌀ 0.39" (10 mm) Total length of drill bit: 2.8" (70 mm) W/ blow out jets to clean dowel holes 1 dowel drill Glue injecting and dowel insertion station w/ 1 dowel tool Dowel: ⌀ 0.31" (8 mm) Dowel length: 1.2" - 1.4" (30 - 35 mm) Dowel projection: 0.28" - 0.55" (7 - 14 mm) Adjusted to 14 mm Tolerances for wood dowels Dowel length: +/- 0.039" (1 mm) Dowel diameter: 0.0039" / 0.0079" (+0.1 / -0.2 mm) Glue delivery system: Graco Husky 307 Glue Pump (made in USA) Eliminates glue-fouling moisture and lubricants and nozzle-clogging contaminants found in compressed air, as well as the accelerated oxidation of glue that necessarily occurs when using compressed air to directly pressurize the glue system Dust extraction: 1 x 2.36" (60 mm) (~200 CFM) Dimensions of the table: 100" (2540 mm) Approximate dimensions: 100" x 55" x 71" Approximate weight: 2,200 lbs (1,000 kg) Taurus Craco offers - start-up supervision service | turnkey installations | operator training | machine reconditioning | PM service packages – Please contact TCMI customer service for more information.  --- ** Note: Information on or derived from the attached PDF document may not apply to listed machine.**

Voltage: 600V / 3ph / 60 Hz
Made in: Germany
