| Swing | 17" | 431.8 mm |
| Centers | 39.3" | 998.22 mm |
| Spindle Bore | 2.2" | 55.88 mm |
| Power | 7.5 hp | 5.6 kW |
| RPM | 2,800 RPM | 2,800 RPM |
| Swing Over Cross Slide | 9" | 228.6 mm |
| Control | CNC (CENTROID) | CNC (CENTROID) |
| Dimensions | 88.5" X 77" X 76" | 88.5" X 77" X 76" |
| Weight | 5,280 LBS. | 5,280 LBS. |
