USED 2020 DMG MORI DMU 50 GEN III
Overview
Description
2020 DMG Mori DMU 50 Gen III 5-Axis Vertical Machining Center with Siemens 840D SL CNC, 25.6" X travel, 20k rpm spindle, 60 ATC, and chip conveyor. Equipped with a probe and bandpass filtration. Primarily used in medical applications.
Specifications
| X Travel | 25.6" | 650.24 mm |
|---|---|---|
| Y Travel | 20.47" | 519.94 mm |
| Z Travel | 18.7" | 474.98 mm |
| Spindle Speed | 20000 rpm | 20,000 RPM |
| Tool Capacity (ATC) | 60 | 60 |
| Table Size (W) | 24.8" | 629.92 mm |
| Table Size (L) | 19.6" | 497.84 mm |
| Main Spindle Motor | 28 hp | |
| Spindle Taper | HSK 63 | HSK 63 |
| Spindle Nose To Table Top | 5.9” - 24.6” | 5.9” - 24.6” |
| Table Type A-Axis Trunnion Tilt Range | -5+100 DEG | -5+100 DEG |
| Part Probe | Yes | Yes |
| Tool Probe/Auto Tool Length Measurement | Yes | Yes |
| B-Axis (Table Swivel) | 360 DEGREES | 360 DEGREES |
| Rapid Traverse Rates: X Axis Y Axis Z Axis | 1654 IPM/ 1654 IPM/ 1654 IPM | 1654 IPM/ 1654 IPM/ 1654 IPM |
| Chip Conveyor | YES | YES |
| Control | CNC (CELOS with Siemens 840D SLIMline CNC Control) | CNC (CELOS with Siemens 840D SLIMline CNC Control) |
| Weight | 16,500 lbs | 16,500 lbs |
MAX TABLE LOAD 660 LBS
TOOL DIAMETER 3.14”-5.11”
TOOL LENGTH 11.8”
TOOL WEIGHT 13.2 LBS
MAX WORKPIECE HEIGHT 11.8”
Equipped With
SIEMENS 840D SL W/ CELOS CNC CONTROL
PROBING
BANDPASS FILTRATION UNIT
60 ATC
CHIP CONVEYOR
CLEAR VIEW ROTATING WINDOW SYSTEM
TRANSFORMER (CHECKING)
ALL WORK WAS MEDICAL. TITANIUM, MEDICAL GRADE PLASTIC.
ALL AVAILABLE MANUALS
