USED OOYA RE3-2000

Used OOYA Radial Drill Model RE-3 2000, 6.5-foot, 19-11/16" Column, Japanese made, 15.75" Quill Travel
The Ooya RE3-2000 is a heavy-duty Japanese radial arm drill with a 2000mm (approx. 6.5 ft) arm and 19.6" column diameter. Key specs include a 75mm (2.95") drilling capacity in steel, #5 Morse Taper, and spindle speeds ranging from 20-2180 RPM. It features hydraulic clamping, power feed, and roughly a 10 HP motor.
Ooya (or OOYA) is a Japanese machinery manufacturer recognized for producing high-quality, heavy-duty industrial radial drilling machines and CNC vertical machining centers. The company is known for robust, all-geared machines, with many models from the late 20th century still in operation today.

Dimension:

Model: RE3-2000
Arm Length: 2000 mm 78.74"
MAXIMUM DISTANCE SPINDLE TO COLUMN 79-1/2"
MINIMUM DISTANCE SPINDLE TO COLUMN 16-1/8"
Column Diameter: 500 mm 19.68"
Drilling Capacity (Steel): 75 mm 2.95"
Drilling Capacity (Cast Iron): 92mm 3.625"
BORING IN STEEL 7-7/8"
BORING IN CAST IRON 11"
Spindle Taper: #5 Morse Taper MT#5
Spindle Speed Range: (16 steps) 20 – 2180 RPM
Spindle Travel: (400mm) 15.75"
Vertical Arm Travel: (820mm) 32.25"
Max Distance (Spindle to Base): 66.875"
Motor: Approx. 10 HP
RANGE OF FEEDS(18) 0015" - .125" PER REV
APPROXIMATE MACHINE DIMENSIONS 121"L x 49-1/4"W x 117"H HEAD DOWN
APPROXIMATE MACHINE WEIGHT 15,000 LBS.

Features:
Clamping: Hydraulic clamping for head, column, and arm
Structure: Heavy-duty, rigid construction
Power elevation & Clamping of Arm on Column
Coolant: Integrated coolant system
Table & T-Slot Base
