Used

USED SUNNEN MBB-1660

Ohio, United States
Asking Price
USD $4,950.00
1 available
994Listings|72Followers
Overview
Hones

6.5” SUNNEN “MBB-1660” PRECISION HORIZONTAL HONE - 16 Honing Tools

Specs
Mandrel Dia. (min)
0.06"
1.524 mm
Mandrel Dia. (max)
6.5"
165.1 mm
Stroke (min)
0.125"
3.175 mm
Stroke (max)
16"
0.4 m
Horz/Vert
'Horz'
'Horz'
Dimensions
30” x 60” x 63”
30” x 60” x 63”
Weight
630 LBS
630 LBS

MBB1660 SUNNEN HORIZONTAL HYDRAULIC HONE
Serial No 89456, Model MBB1660

EQUIPPED WITH:
Self Energizing Band Type Spindle Brake
16 Honing Tools

CATALOGUE SPECIFICATIONS:
Diameter Capacity, Minimum .060"
Diameter Capacity, Maximum 6.5"
Work Length, Maximum 16"
(12) Spindle Speeds, Range 200 to 2500 RPM
Spindle Drive Motor, Horsepower 0.5 HP
Floor Space Required, W x D 2'6" x 5'
Overall Height 5'3"
Weight, Approximately 630 LBS

F.O.B. OUR WAREHOUSE
