•Extra-long precision ground tables provide a stable work surface.
115/230V 1PH 1HP 13/6.5AMPS
Model Number|4225
Stock Number|4225.201 (1 HP, 1Ph, Helical)
Infeed Table Travel|1/2″
Cutterhead Speed|5,500 (RPM)
Number of Knives (helical)|28 Inserts
Maximum Depth of Cut |1/8″
Rabbeting Capacity|1/2″
Dust Port Diameter|4″
Table Dimensions|60-3/4” L x 5-3/4” W
Table Height|31-1/2″
Fence Dimensions|29”L x 3-3/4”H
Fence Tilts|45°, 90°, 135°
Positive Stops|45° and 90°
Motor 1Ph|1HP, 115V/230V, Prewired 115V (1Ph, 13/6.5 Amp)
Net Weight|240 lbs.
Gross Weight|375 lbs.
