4375 | Safety Speed | Sanders-Wide Belt
Overview
Description
The 43″ Wide Belt Sander features a 75” belt, providing 25% more abrasive surface than the smaller 60” belt machines. The larger belt translates to increased capacity, less heat accumulation, less maintenance and fewer belt replacements. With a fully adjustable platen these sanders will deliver a perfect smooth finish every time. Standard Equipment:
Specifications
Weight|1946 lbs
Dimensions|60 × 62 × 71 in
Max. Working Length|Unlimited
Min. Working Length|12″/305mm
Main Motor Options|10 Hp, Single Phase (1~), 220 Volt, 20 Hp, 3 Phase (3~), 208 Volt / 230 Volt, 30 Hp, 3 Phase (3~), 208 Volt / 230 Volt
Max. Working Width|42″/1070mm
Max. Working Thickness|7 1/4″/184mm
Min. Working Thickness|1/8″/3mm
Vacuum Requirement|1000 CFM
Conveyor Speed|0-18 FPM
Durometer of Contact Roller|60
Sanding Belt Size|43″ x 75″
Sanding Belt Width|43″
Sanding Belt Length|75″
