220V 1PH 7.5HP 38AMPS
tock No. (7.5HP, 1Ph, Byrd)|4455.103.B
Stock No. (10HP, 3Ph, Byrd)|4455.104.B
Maximum Stock Width|22″
Maximum Stock Thickness|9″
Minimum Stock Thickness|1/8″
Minimum Stock Length|10″
Dust Port Diameter|5″
Minimum CFM Required|900 CFM
Infeed Roller Diameter |3″
Outfeed Roller Diameter|3-5/16″
Feed Speeds|20 and 30 FPM
Bed Rollers|2, Adjustable
Table Size|23-3/4” x 32-1/4”
Cutterhead Diameter|3″
Cutterhead Speed|5,000 RPM
Number of Knives (straight)|4
Number of Knives Byrd|110 Inserts
Footprint|44”L x 22”W
Table Support|2-Column
Motor 1Ph|7.5HP, 220V Only (38 Amp)
Motor 3Ph|10HP, 240V/440V*, Prewired 220V (26/13 Amp)
Overall Dimensions|45”W x 32”D x 50”H
Net Weight|1,340 lbs
Gross Weight|1,550 lbs.
