USED 2019 HORIZON RD-4055DM

Max. Sheet Size: 15.74" x 21.65"
Min. Sheet Size: 7.875" x 10.83"
Feeder Stacker Height: 19.68"
Material Thickness: 127.9 to 400gsm Die Cutting: Max. 0.5 mm or 0.019" Creasing: Max. 0.3 mm or 0.011"
Production Speed: 6,000 cycles per hour
Double sheet detection: Ultrasonic and mechanical
Processed Material: Normal paper, Coated paper, Cardboard The sheets below cannot be processed: Sheet whose back side is laminated (cover with polypropylene) Plastic film
Available Cutting Area: 14.8" W x 20.8" L
Die Size - Upper Die: Max. 15.74" W x 22.04" L Min. 6.30" W x 3.94" L
Upper Cutting Blade Height: 0.0315"
Gripping width for Repeat Die Cutting: 6.69"(includes the cut product at least)
Dimensions: With separator: 141.2" W x 32.3" D x 47.1" H Weight: 1,962.45 lb
Air Requirements: Rated Output of Prime Mover(Reference): 0.75 kW Maximum Operating Pressure: 0.8 MPa Minimum Required Pressure: 0.6 MPa or more Minimum Discharge: 85 Liters per minute Type: Oil-free Type
Electrical: Single Phase 200 to 240 V, 50 or 60 Hz
Unique id: 20260303DNC041301
