USED 1990 AMADA COMA 506072

Amada COMA 506072 50-Ton CNC Turret Punch Press

Heavy-duty CNC turret punch press designed for punching, nibbling and producing formed features in sheet metal. Features a 50-ton punching capacity, 44-station turret and automatic sheet repositioning for processing larger workpieces.
-
Specifications

Manufacturer: Amada
Model: COMA 506072
Year: 1991
Machine Type: CNC Turret Punch Press
Punching Capacity: 50 Tons
Turret Capacity: 44 Stations
Maximum Sheet Size With Repositioning: Approximately 60" × 72"
Maximum Material Thickness: Approximately 0.250" Mild Steel
Maximum Punch Diameter: Approximately 4.5"
Hits Per Minute With 1" Movement: Approximately 200
Maximum Positioning Speed: Approximately 2,559 IPM
Turret Speed: Approximately 30 RPM
Main Motor: Approximately 7.5 HP
Automatic Repositioning: Yes
Machine Weight: Approximately 36,000 lbs.
Overall Dimensions: Approximately 186" L × 195" W × 104" H
-
Equipped With

44-station bi-directional turret
Automatic sheet repositioning
CNC control
Powered X- and Y-axis sheet positioning
Workholding clamps
Ball-transfer worktable
Mechanical punch-drive system
Operator control station
-
Machine Description

The Amada COMA 506072 is a heavy-duty CNC turret punch press designed for processing medium- and heavy-gauge sheet metal. Its 50-ton punching capacity provides greater forming and punching capability than smaller 20- and 30-ton turret punches.

The machine is equipped with a 44-station turret, allowing multiple punch sizes and shapes to remain installed for efficient production. Automatic repositioning extends the effective working area and permits processing sheets approximately 60" × 72", depending upon tooling, clamp locations and programmed repositioning.

This machine is suited for producing electrical enclosures, equipment panels, structural sheet-metal components, brackets and other fabricated products requiring repeated holes, profiles and formed features.
-
