NEW OMRON E2F-X1R5F1

The Omron E2f-x1r5f1 is an inductive proximity sensor designed for industrial automation applications. This M8 threaded cylindrical sensor features a 1.5mm sensing distance and PNP output configuration with normally open contacts, making it ideal for detecting metallic objects in manufacturing and automation systems.
Specification
Value
Brand
Omron
Model/Part Number
E2f-x1r5f1
Type
Inductive Proximity Sensor
Series
E2F-X
Thread Size
M8
Sensing Distance
1.5mm
Output Type
PNP
Output Function
NO (Normally Open)
Supply Voltage
12-24 VDC
Voltage Range
10-30 VDC
Current Consumption
17mA max
Switching Current
200mA max
Response Frequency
2kHz
Connection Type
Pre-wired Cable
Cable Length
2m
Housing Material
Polyarylate Resin
IP Rating
IP67
Operating Temperature
-25°C to +70°C
Body Style
Threaded Barrel
Length
30mm
Shielding
Shielded
We warranty all items for 30 days from date of purchase.

SKU: AI0477
UPC: 679523686246
Condition: New
Availability: In Stock
Weight: 2.00 LBS
Width: 7.00
(in)
Height: 6.00
(in)
Depth: 7.00
(in)
Shipping: Calculated at Checkout
GTIN: 679523686246
Output Type: PNP
Sensor Type: Inductive
Full Load Amps: 17mA max
Manufacturer: Omron
Part Number: E2F-X1R5F1
Shelf: K-41
Model: E2F-X1R5F1
MPN: E2F-X1R5F1
Type: Inductive Proximity Sensor
