2017 Mazak Integrex i-200ST CNC Milling and Turning Center offers a 25.91" max swing, 5,000 RPM main and sub spindles, 72-tool ATC, and high-pressure coolant. Features include the Y-axis, B-axis, and C-axis, equipped with a chip conveyor and sub-spindle.
| Maximum Swing | 25.91" | 658.11 mm |
| Max Turning Diameter | 25.91" | 658.11 mm |
| Main Spindle Bore/Max Bar Capacity | 2.99"/ 2.6" | 2.99"/ 2.6" |
| Tail Stock/Sub Spindle | Sub Spindle | Sub Spindle |
| Maximum Cutting Length | 59.8" | 1,518.9 mm |
| X-Axis Travel (X1, X2, X3) | 24.21/ 9.06 | 24.21/ 9.06 |
| Z-Axis Travel (Z1, Z2, Z3) | 60 | 60 |
| Y-Axis Travel (Y1, Y2, Y3) | 9.84" | 9.84" |
| C-Axis Indexing (1, 2) | YES | YES |
| W-Axis Travel Sub Spindle | 56 in | |
| Main Spindle Chuck Size | 8" | 203.2 mm |
| Main Spindle Chuck Type | Hydraulic | Hydraulic |
| Main Spindle Bore Diameter | 3" | 76.2 mm |
| Main Spindle Maximum Bar Work | 2.56" | 65.024 mm |
| Main Spindle Speed | 5,000 RPM | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 30 | 30 |
| Sub Spindle/2nd Spindle Chuck Size | 8 | 8 |
| Sub Spindle/2nd Spindle Bore Size | 2.56 | 2.56 |
| Sub Spindle/2nd Spindle Chuck Type | Hydraulic | Hydraulic |
| Sub Spindle/2nd Spindle Speed | 5,000 RPM | 5,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 30 | 30 |
| ATC Magazine Capacity | 72 | 72 |
| Turret Tool Positions 1, 2 | 9 | 9 |
| Turret Rotary Tool Spindle Speed 1, 2 | 12000 | 12000 |
| B-Axis Travel | -30° ~ 210° | -30° ~ 210° |
| B-Axis Head Indexing | 240 deg | 240° |
| Bar Feed | Yes | Yes |
| Chip Conveyor | Yes | Yes |
| Tool Eye Automatic Front Spindle | Yes | Yes |
| High Pressure Coolant System (PSI) | 1000 | 1000 |
| Work Measuring System (Probe) | YES | YES |
| Lower Turret Positions | 9 | 9 |
| Control | CNC (MAZATROL SMOOTH X) | CNC (MAZATROL SMOOTH X) |
SUB-SPINDLE
12,000 RPM MILLING SPINDLE
36 ATC
Y-AXIS
B-AXIS
C-AXIS
CHIP CONVEYOR
