USED 1990 BLISS SC2-500-108-60

500-ton Bliss SC2-500-108-60 Straight Side Mechanical Metal Stamping Press, Year 1989 Full Rebuild In Process!

Tonnage: 500
Stroke: 14 inches
Shut Height: 44 inches
Adjustment: 12 inches
Bed Size: 108" LR x 60" FB
Ram Area: 108" LR x 60" FB
SPM: 20-50 VSPM

Standard Specifications500-ton Bliss Straight Side Mechanical PressMetal Stamping Press Model# SC2-500-108-60Full Remanufacture in Process - Complete 202514" Stroke44" Shut Height (SDAU) on Bed36" Die Height on Bolster12" Motorized Adjustment108" LR x 60" FB Bed Area108" LR x 60" FB Slide Area20-50 VSPM Equipment and FeaturesAir Clutch and BrakeAir CounterbalancesRecirculating Lube Syste8" T-Slotted Bolster T-Slotted Ram with Knockouts(2) Plug in Pedestal Palm Button Stations75 HP Dynamatic Eddy Current DriveHydraulic Tie Rod NutsLight Curtains Front and Back37" Wide WindowsFloor StandingFootprint: 148" x 102" 245" Max. Overall HeightClick for more 500-ton Press OptionsThis 500-ton Bliss Rebuilt Metal Stamping Press can be seen under power upon Completion at S&G Press Warehouse.  Do not hesitate to call or email S&G Press for further details and pricing.Now in the final stages of a complete rebuild, this 500-ton Bliss Model SC2-500-108-60 straight side mechanical press will soon be ready to boost your production. Our meticulous remanufacturing process ensures this press performs like new, offering a 14" stroke, 44" shut height, and a massive 108" x 60" bed area ideal for large stamping applications. Equipped with new light curtains, hydraulic tie rod nuts, and a powerful 75 HP drive, this press delivers both power and precision. The complete remanufacture process ensures enhanced reliability, improved safety, and maximized performance. This high-quality, reconditioned Bliss press is available for sale now, with completion slated for late 2025. Contact S&G Press for detailed specifications and to reserve this exceptional machine for your facility.Bliss Mechanical Metal Stamping Press For Sale, Used Presses For Sale, Straight Side Mechanical Presses, Rebuilt and Remanufactured Presses
