NEW 2006 SCHIESS FOREIP 40 DZ 12-400/500-500/180
Overview
Description
2006 Rebuilt SCHIESS MOWEG DOUBLE COLUMN, VERTICAL TURRET LATHE, 40 DZ, CNC 840D
The Schiess-Moweg (or Schiess-Froriep) VTL Model 40 DZ is a heavy-duty, often retrofitted, vertical boring mill, commonly featuring a table diameter around 3,500 mm (137 inches) to 5,200 mm, a swing capacity up to 4,000–5,200 mm, and a maximum workload capacity around 50–60 tons. It is designed for large-diameter turning, frequently updated with Siemens CNC controls.
Specifications
| Table Dia | 157.5" | 4,000.5 mm |
|---|---|---|
| Swing | 196.8" | 4,998.7 mm |
| Work Ht-U/R | 196.8" | 4,998.7 mm |
| Power | 200 hp | 149.1 kW |
| RPM | 63 RPM | 63 RPM |
| Control | CNC (Siemens 840D) | CNC (Siemens 840D) |
| Dimensions | 30.35' H | 30.35' H |
Manufacturer: Schiess / Schiess-Moweg / Schiess-Froriep
Table Diameter: 4,000 mm (157.5")
Maximum Swing: 5,000 mm (196.8")
Maximum Turning Height: 5,000 mm (196.8")
Cross Rail Adjustment: 3200 mm (126.0")
Vertical Ram Stroke-adjustment: 1800 mm (70/9")
Ram Head dimension: 250 x 210 mm (9.84" x 8.3")
Faceplate Turning Speed 0,63 - 63 U/min (range -stepless)
Max. Workpiece Weight 80.000 kg 88 Tons
Total Power Requirement 150 kW 200HP
Vertical Ram Travel (Z-axis): 1,500 mm - 1,800 mm
Control System: Siemens Sinumerik (840D)
Machine ca. Height above floor 30.35"
Location: Germany
Equipped With
Technical Parameters
with CNC SIEMENS 840 D
sidehead, vertical movement 2170 mm
horizontal movement 1000 mm ( dia. 4500/2500 mm )
Y-axis 2500 mm
automatic. toolchanger
operator lift, chip conveyor, coolant attachment
